Cascade Control Loop Simulator
www.instrunexus.com
Steam Heat Exchanger P&ID (Training View)
Cold Fluid: Blue
Steam: Orange
Hot Outlet: Red
Control Signals: Green
ISA-style instrument bubbles and control signal paths are shown. In cascade mode, TIC-101 sends flow setpoint to FIC-101.
Control Panel
Simulation Mode
Mode: Single loop (TIC directly manipulates TV-101).
Process Inputs
PID Tuning: Temperature Controller (TIC-101)
PID Tuning: Flow Controller (FIC-101)
Disturbance Injection
Each disturbance creates a temporary upset and then decays back to base settings.
Live Values and Loop Activity
Primary Loop Action
Secondary Loop Action
Outlet Temp: 0.0 degC
Steam Flow: 0.0 kg/s
TIC Output: 0.0 %
FIC Output: 0.0 %
Valve Position: 0.0 %
Steam Pressure: 1.00 pu
Cascade control uses a fast secondary loop (flow) inside a slower primary loop (temperature). The secondary loop handles steam-side disturbances before they propagate to outlet temperature. This improves disturbance rejection, reduces oscillation, and allows tighter temperature control. Typical industrial applications include heat exchangers, boilers, furnaces, and reactors.
Live Trends (100 ms updates)
Traces: TT-101 Reading (Outlet Temperature), Temperature SP, Steam Flow, TIC Output, FIC Output, Steam Pressure Disturbance
